Applications:

 For METRO Traction substations

Technical Specifications:

Type of rectifier: silicon diode

Configuration: 2 × parallel three Phase Bridge (12 pulses)

Type of installation: indoor

Enclosure degree: IP 31

Method of cooling: AN

Output voltage: up to 3000 V DC

Rate Power: up to 4500 KW

Rate current: up to 5000 A DC

Standard: IEC 146 class VI

Max. ambient temperature: 40

Main Parts:

Diode bridge

Terminal Box of auxiliary connections

Complete diode module (Diode heat sink & RC circuit)

Control box of the rectifier

The power and control system of drilling rigs (SCR & MCC System) is one of the products of this center that has been designed and manufactured since the year 2001. The power system and control of drilling rigs in the center of engineering and construction of drilling rigs were 100% localized.

The construction of a metal structure (SCR room), SCR units, MCC units and existing transformators are carried out in accordance with international standards at the 1000 square meter electric power.

Other equipment is supplied as Plug & Recipient Plug and Air Condition system and installed in SCR room. The center manufactures or provides the equipment with the design, engineering, construction and assembly capabilities according to the technical specifications and the AVL desired by the employer, and then assembles all equipment in the SCR Assembly Assembly Workshop with facilities and equipment And perform cabling and electricity operations.

Possibility of cold and hot testing at the workshop in the presence of employer's representatives. After construction and delivery, During the gurantee period, the electrical and mechanical experts of the center will be present full-time at the employer's Yard. in the warranty period, the required parts will be provided by this center.

Solar inverters are an essential part of a solar power plant, they convert the direct current (DC) generated by the solar panels into alternating current (AC). In general, there are 2 types of solar inverters, off grid and on grid. Off grid solar inverters are used separately from the grid in small-scale as island power plants and at low powers.

On grid solar inverters connected to the grid are made in two types, central and string topology. String inverters are used in low-power applications that require the installation of several strings of solar arrays, and provide the possibility of providing better efficiency in absorbing solar energy and producing electrical energy in shadow and cloudy conditions.

Central inverters are used in high power applications and mainly in high power solar power plants. By reducing one stage of power conversion (power converter), these inverters can save money and are a more economical option. Especially in high power plants, this structure is offered as the best option.

High Current Transformer Rectifier

 Applications:

Oil, Gas and Chemical Industries: Pumps, Compressors, Extruders, Mixers and Blowers

Cement, Mining and Minerals Industries: Conveyors, Crushers, Mills, Mine Hoists, Fans and Pumps

Power Generation Industry: Fans, Pumps, Conveyors and Coal Mills

Water and Wastewater Industry: Pumps

Transportation Industry: Traction Electro motors of Metro, Trains and Ships

Metals Industries: Fans and Pumps

Pulp and Paper Industries: Fans, Pumps, Refiners, Vacuum Pumps and Chippers

Other Applications: Test Stands and Wind Tunnels

Key Features:

Compatible with old and new electric motors, Modular design and high reliability, Low Harmonic  Distortion at input current and output voltage, Five level inverter, 24 pulse rectifier, Industrial HMI and communication, Compact design

Technical Specifications

Input Supply: 4.16 to 20 kV - 50/60 Hz

Output Voltage: 3.3, 4.16, 6, 6.6 kV

Output Frequency: Up to 120 Hz

Output Power: Up to 10MW

Efficiency: Around 97%

Power Factor: Around 97%

Duty Cycle: Continuous

Cooling Method: Forced Air Cooled/ Water Cooled

Operating Temperature: 1 to 40 °C

Protection Class: IP21 to IP42

Online - Single,Double, Parallel, Hot Standby and Load share

High power - up to 250 KVA single phase and 500 KVA three-phase (higher power by order)

High reliability and efficiency

High power quality

Low output distortion

Fast Response to step loading

accordance with IEC, IPS, NEMA standards

Automatic charge of Different types of battery

power supplying of batteries and Load simultaneously

• Online double conversion
• High power factor  > 0.99
• up to 8 parallel redundancy
• Full DSP control
• Cold Start
• Automic restart
• economic operation mode
• Emergency Shut Down
• Rectifier and inverter with IGBT Base and PWM control
• Support generator input
• Options: SNMP card/Relay card/Parallel board

 HVDC Power supply for vacuum coating

Applications:

Fine and homogeneous coating

Production unalloyed material

Technical Specifications

Input voltage: 380 V/50 Hz/ 3 Ph

Output voltage: 0-30 kV DC/ 0-4 ADC

Type of control: By PLC adjusting voltage and current and process

Cooling: air cold, oil cold (ANAN, ONAN)

Duty cycle: continues

Multiply Voltage Power Supply (HVDC)

Applications:

Research Physics lab

Hipot tests

Technical Specifications

Input voltage: 220V/ 50 Hz/ 60 Hz / 1 or 3 Ph

Output voltage: 0-200 kV DC/ 0-10 mA

Type of control: adjustable & stabilizer voltage

Cooling: dry type

Duty cycle: continues

% Ripple: less than 1%

The JDEVS inverters are Submited  continuous Load and safe For special applications. The range of this production is from 1KVA to 500KVA (more power to order) designed according to international standards and manufacturing according to customer requirements.

High Voltage Transformer Rectifier

Applications:

Electrostatic Precipitators

Vacuum Coating

Technical Specifications

Input voltage: 380kV/ 50 Hz/ 60 Hz

Phase: single Phase

Apparent Power: 10kA-350kVA

No load Peak voltage: 30kV up to 140kV DC

Impedance voltage: (30 + 5)%

Output current: 200 - 2500 mA

Protected by DMCR relay

Hermetic case

Oil immersed type

Microprocessor based controller

HV/LV control cabinets

Dry type Transformers

Applications:

Drilling rigs

Transformers

Motor – drives

Lightings

Rectifiers

Furnaces, welding, & high current applications …

Technical Specifications

Input voltage: up to 1000V/50 Hz/ 1 or 3 Ph

Output voltage: up to 1000 V/50 Hz/ 1 or 3 Ph

Rating Power: 2.5 kVA- 3.5 MVA

Conductor Type: copper & Aluminum

Single/three phases

Buck & Boost (one/three phases)

Auto Transformers

Type of control: adjustable & stabilizer voltage

Cooling: dry type

Duty cycle: continues

% Ripple: less than 1%

Battery Bank voltage measurement

temperature of battery room measurement

Battery temperature measurement

Electroplating DC power supplies

Applications:

Creating additive metallic surface on the metals for increasing their period of life, protection aims and improving physical and chemical characteristics

Technical Specifications

Input voltage: up to 20 kV/ 50 Hz / 1 or 3 Ph

Output current: up to 20 kA DC

Output voltage: up to 500 V DC

Cooling: AN, ANAN, ONAF, ONAN, WFAF

Auto/manual control of output voltage & current

Electronic control by microprocessors

Standard port for connection to computer

Suitable for industrial and laboratorial environment
